What Is the Maximum Motor Cable Length for the Siemens 6SL3120-2TE21-8AC0 in a 400V System

When designing a servo drive system for industrial automation, cable sizing and length restrictions often determine reliability. For engineers working with the Siemens 6SL3120-2TE21-8AC0 – a 20A booksize power module within the SINAMICS S120 family – the maximum allowable motor cable length directly impacts EMC compliance, voltage drop, and thermal protection. In a standard 400V AC industrial network, this parameter is not a fixed number; it depends on cable type, shielding, switching frequency, and ambient temperature. This guide provides definitive answers based on Siemens technical manuals and practical field experience, with integration support from Yueyang Tongtu, a specialized distributor for SINAMICS drive components and retrofit solutions.

Core Specification – Maximum Length

According to Siemens Drive Technology Configuration Manual (valid for firmware 4.8 and above), the Siemens 6SL3120-2TE21-8AC0 allows the following maximum motor cable lengths in a 400V system (rated voltage 380–480V AC, 3-phase):

These values assume a maximum ambient temperature of 40°C and a motor insulation rating of 1000V (IEC 60034-25). Exceeding these limits triggers overtemperature alarms (F30011) or overvoltage trips (F30002) due to reflected wave reflections.

Critical Derating Factors

The Siemens 6SL3120-2TE21-8AC0 uses IGBT switching at default 4 kHz. Every 1 kHz increase above 4 kHz reduces maximum length by approximately 15%. For instance, at 8 kHz, shielded length drops from 100 m to 65 m. Additionally, parallel motor operation (common for gantry axes) requires reducing length by 30% per additional motor. Yueyang Tongtu recommends always using symmetrical shielded cables with 360° grounding at both ends – this alone improves EMC performance and allows you to safely approach the upper limits listed above.

Practical Installation Checklist

• Use copper conductors only (aluminum is not approved).

• Maintain separation from power lines (≥ 200 mm) to avoid capacitive coupling.

• Install an output reactor (Siemens 6SL3200-0BE21-8AA0) for runs > 150 m – this also reduces motor heating.

• Measure voltage drop at motor terminals; it must not exceed 5% of nominal voltage (i.e., 20V for 400V).

Three Essential FAQs for the Siemens 6SL3120-2TE21-8AC0

Q1: Can I extend the motor cable beyond 150 m if I use a shielded cable with a higher cross-section, such as 4 mm², for the Siemens 6SL3120-2TE21-8AC0 in a 400V system?

A1: Yes, but with strict limitations. Increasing cross-section to 4 mm² reduces resistive losses, so unshielded length can reach 200 m and shielded up to 130 m at 4 kHz. However, the drive’s internal output capacitance limits are based on cable capacitance per meter (typically 150–200 pF/m). A 4 mm² cable has higher capacitance (≈ 250 pF/m), which increases charging current and may trip overcurrent alarm F30001. Therefore, 4 mm² is only permissible if you lower switching frequency to 2 kHz and add a du/dt filter. Siemens does not officially approve 4 mm² for standard configurations – always simulate with SIZER software. Yueyang Tongtu offers pre-configured cable kits with verified capacitance values for lengths up to 180 m.

Q2: How does the ambient temperature at the cabinet affect the maximum cable length for the Siemens 6SL3120-2TE21-8AC0?

A2: The drive’s datasheet specifies 40°C ambient. For every 5°C above 40°C (up to 55°C max), derate both current and cable length by 10%. For example, at 50°C ambient, the maximum shielded length (2.5 mm²) drops from 100 m to 80 m. This is because higher ambient reduces the heat dissipation capability of the IGBT module, and longer cables increase pulse-frequency losses. Conversely, at 25°C ambient, you gain a 5% margin, so 105 m shielded is achievable without derating. Always mount the Siemens 6SL3120-2TE21-8AC0 in the lower section of the cabinet (cold air intake) to maintain stable thermal performance. Yueyang Tongtu provides thermal simulation reports for custom cabinet designs upon request.

Q3: What is the exact procedure to measure actual cable length limitation during commissioning of the Siemens 6SL3120-2TE21-8AC0, without relying on theoretical tables?

A3: Use the drive’s built-in “motor cable test” function (parameter p1910 = 1) followed by a stationary measurement (p1910 = 3). This measures leakage capacitance and inductance. If the measured capacitance exceeds 0.8 µF, the drive will issue alarm A07903 and automatically reduce the maximum allowable length to 80% of the table value. For a precise field check: apply a 100 Hz sinusoidal voltage at 50% rated current and record the phase shift between voltage and current – a phase angle below 15° indicates excessive cable capacitance. Additionally, monitor the DC link voltage ripple via r0070; ripple above 15V at full load confirms that cable length is too long. Yueyang Tongtu engineers recommend performing this test before final wiring, as it saves days of troubleshooting later.

Recommended Configuration Table (400V, 4 kHz, 40°C)

Final Engineering Verdict

The Siemens 6SL3120-2TE21-8AC0 is remarkably flexible, but its motor cable length is not a simple “one-size-fits-all” value. Always cross-reference switching frequency, ambient temperature, cable capacitance, and filter usage. For mission-critical axes, stay 20% below the maximum listed values to guarantee long-term insulation life. Yueyang Tongtu maintains a dedicated technical hotline for SINAMICS S120 – our team has handled over 500 field installations with this exact module, including customized cable assemblies tested for 400V systems.

Contact Us – If you need a verified cable length calculation for your specific layout, or if you require a pre-tested Siemens 6SL3120-2TE21-8AC0 replacement unit with same-day shipping, reach out to Yueyang Tongtu today. We provide free SIZER configuration support, on-site commissioning assistance, and a full range of original Siemens accessories. Visit our website or email our engineering desk – we guarantee a technical response within 4 business hours. Let us help you keep your drives running safely, reliably, and within spec.
